Code 8208PF Flush distribution board, 4 modules Flush distribution board, 4 modules. White frame and fume door.
│Price: 12 €
COMPLEMENTARY PRODUCTS
|
 Features |
| Enclosure type | Distribution | Door opening | Vertical |  |
||
| Installation method | Flush in work | Terminal block included | No | |||
| Use | Domestic / Tertiary | Fixation System (For surface) |
Inside | |||
| Location type | Inside | Sealable | No | |||
| No. Modules (18 mm) | 4 | Lid closure system | Metal screw | |||
| Modules per row | 4 | Door closing system | Pressure | |||
| Metallic DIN profile | Yes | Reversible door | Yes | |||
| Dimensions outside (mm) (width x height x depth) |
165x300x95 | Possibility of putting lock | No | |||
| Flush dimensions (mm) (width x height x depth) |
140x270x72 | Separate covers or doors on the boxes |
Yes | |||
| Case material | Insulation | Possibility of mounting DIN rail |
Yes (included) | |||
| Frame and door material | Insulation | |||||
| Case color | Black | |||||
| Cap color | White | |||||
| Door color | Fume |
 Technical data and regulation |
| Protection Degree (IP) | IP40 | CE marking | Yes | |||||||
| Protection Degree (IK) | IK08 | UK marking | Yes | |||||||
| Insulation class | Class II | CMim marking | Yes | |||||||
| Fire resistance (GWEPT) | 650 ºC | According to Regulations UNE/EN | UNE-EN 62208:2012 | |||||||
| Heat resistance (Ball pressure) | 70 ºC | According to REBT | Yes | |||||||
| Installation temperature | -5 ºC -> +60 ºC | According to European Directive 2014/35 / EU Low voltage directive |
Yes | |||||||
| Work stress | <400 Vac ; 1000 Vdc | |||||||||
| Free of halogens | Yes |
