PTFA 60.000
|
|
|
|
|
|
Technical data
| Data | PTFA 60.000 | |
| Cut-out | 291 x 291 mm | |
| Degrees of protection according to EN 60529 / UL 50 | IP 33, IP 54 | |
| Filter mat quality class according to EN 779 | IP 54 | G4 |
| IP 33 | no filter mat | |
| Colour | RAL 7035, different colours available on request | |
Further technical details and dimensions can be found in the download section on this page under product sheet
Downloads
| Description | Language | Type | Size | Download |
| Conformity PTF/PTFA 6xxxx | English, German |  |
740 KB | │DOWNLOAD |
| Conformity UKCA | English | |
430 KB | │DOWNLOAD |
| Manual PTF/PTFA 6 4th | English, French, German | |
1.7 MB | │DOWNLOAD |
| Filter 290x70 IP54/Type12 | English, German | |
33 KB | │DOWNLOAD |
| Product sheet | English | |
540 KB | │DOWNLOAD |
| 3D-model (STEP) | English |  |
2.7 MB | │DOWNLOAD |
| UL listed certificate | English | |
190 KB | │DOWNLOAD |
| UL recognized certificate | English | |
170 KB | │DOWNLOAD |
| EAC certificate | Russian | |
250 KB | │DOWNLOAD |
Ordering details
| Ordering details | PTFA 60.000 | |
| Degrees of protection | IP 54 | IP 33 |
| Article number | 11786001055 | 11786000055 |
Article numbers for other types on request
Video
εCOOL Filterfan 4th generation
| DIMENSIONS PTFA 60.000 | ||
  |
||
| A | 291 mm | |
| B | 291 mm | |
| X | 436 mm | |
| Y | 436 mm | |
| Z1 | 72 mm | |
| Z2 | 34 mm | |
 |
